price on request
F3 combines the advantages of the well-known unique MPS (Multi Period Sensing) technology with the new BiPolar technology.
Features:
- Innovative sensitivity selection function “rear plugs”
- Minimizes magnetic influence mine triggers Full configuration for operator needs
- Fully enclosed and protected cables
- Fast and precise target localization
- Sealed construction. Submersion up to 3m.
- RS232 port for data logging
- Search coil configuration
- Extended power supply operating time
- Replaceable power supply unit
- Simple to operate, service, and repair
Effectiveness
Capable of detecting all metallic mines, even those with minimal metal content in soils with any mineralization and salt content.
Ease of Use
No complex switches or scales that could complicate the operator’s work.
Safety
Designed to prevent accidental reduction of sensitivity by the operator, which adds confidence in operating settings. Built-in system for checking and controlling the device’s operating parameters.
Durability
Made of impact-resistant materials and capable of operating in any conditions
Sensitivity Selection Plugs
- Black – Maximum sensitivity for detecting mines with minimal metal content
- Red – Minimum sensitivity for detecting large targets and explosive ordnance
- Yellow – Managed sensitivity for specific applications.
Technical Specifications
| Application | Detection of explosive ordnance, anti-personnel mines, improvised explosive devices, and unexploded ordnance. For military and humanitarian demining. |
| Technology | Pulse Induction: Bi-Polar Multi Period Sensing |
| Operating Frequency | 1,25 kHz +/- 3% PRF |
| Coil (Basic) | 200 mm. Mono |
| Audio Output | Internal speaker and headset |
| Illumination | absent |
| Product ID | 254300 |
| PC Connection | RS 232 |
| Storage | absent |
| Depth Indication | absent |
| Detector Mode Selection | absent |
| Discrimination | absent |
| Timings | Yes, selected by changing the rear plug |
| Ground Balance | Fixed ground balance |
| Pinpoint | absent |
| Sensitivity Adjustment | Sensitivity is regulated by changing the rear caps |
| Noise Reduction | Semi-automatic |
| Threshold Setting | Threshold tone or pulsating tone |
| Target Signal Adjustment | absent |
| Power Source | 4xD-format (Alkaline or rechargeable batteries) |
| Low Battery Alert | Yes |
| Length | from 1500 mm to 750 mm |
| Weight | 3.2 kg with batteries |
